CNC Machining center machine tools
1：The product is constantly being developed and updated,and the latest information shall prevail.
2：The product parameters are standard configurations.For other configurations,please call to inquire.
Item | Spec | Unit | Value |
Travel | X/Y/Z axis | mm | 800/550/550 |
Spindle nose to worktable | mm | 120-670 | |
Spindle centre to column rail surface | mm | 590 | |
Rail type | Roller screw rails | ||
worktable | size（ L*W) | mm | 1000×550 |
Max load | kg | 600 | |
T-slot | No/mm | 5-18*90 | |
spindle | bore（taper/diameter） | mm | BT40φ140 |
speed | rpm | 12000 | |
Transmission type | Direct Drive | ||
feed | X/Y/Z rapid displacement | m/min | 36/36/36 |
Max cutting speed | mm/mi n | 10000 | |
ATC(optional) | Tool exchange mode | Hanging on side | |
Tool bar spec | type | BT40 | |
Tool capacity | tools | 24T | |
Max diameter of tool（with neighbor tool） | mm | 105 | |
Max diameter of tool（without neighbor tool） | mm | 200 | |
Max length of tool | mm | 350 | |
Max weight of tool | kg | 15 | |
Max time of changing tools | sec | 4 | |
spindle | Spindle motor | kw | βis12-12000 |
3 axes servo motor power | kw | βis22-3000*2βis22b-3000 | |
Pump motor of flushing ferri chips | m/h- m | 4-60 | |
accuracy | Positioning | mm | ±0.005/300 |
Repeated positioning | mm | ±0.003/300 | |
Power required | Power consumption | KVA | 25 |
Air pressure | Kg/cm | 6-8 | |
Machine | Size (L*W*H) | mm | 2580*2175*2415 |
Weight | T | 5.5 |
*The specifications of this machine are subject to change without prior notice as the quality improves. Taijet reserves the right of final interpretation. For more information, please contact the corresponding sales staff.
